    Vanadium Oxide Unrefrigerated Detector Thermal Monocular With OLED Display

    Ask Lasest Price
    Brand Name : CONO
    Model Number : Tracer 35LRF
    Certification : ISO,CE,ROSH
    Price : Negotiable
    Payment Terms : L/C, T/T, T/T, Western Union, MoneyGram
    Supply Ability : 10000 PCS PER YEAR
    Delivery Time : 7-30 Days
    • Product Details
    • Company Profile

    Vanadium Oxide Unrefrigerated Detector Thermal Monocular With OLED Display

    Direct Factory Sale Vanadium Oxide Unrefrigerated Detector Monocular Thermal Imaging Camera


    The Tracer LRF offers excellent thermal imaging with its 384x288 17µm <35mK NETD thermal sensor and smooth, high resolution viewing with its frost-resistant 1024x768 HD OLED display and 50Hz frame rate.


    The Tracer LRF can even perform in conditions where temperature differences are minimal, such as during rain/snowfall, cold mornings, fog, etc.

    Offers great optical capabilities with its 35mm objective lens, 10.88x max. magnification, and is capable of detecting distances of up to 1750m. Fitted with a built-in (eyesafe) laser rangefinder capable of accurately measuring distances up to 1000m (±1m).


    Features photo & video capture with its on-board recorder, with all data being saved directly to the units 32Gb internal memory and can be transmitted wirelessly with the dedicated App.


    Features:

    · Sensitive thermal sensor

    · Built-In laser rangefinder

    · Smooth digital zoom

    · HD display

    · Smooth viewing (50Hz frame rate)

    · Built-In battery pack

    · Long operation time

    · High protection rating (IP67)

    · On-Board photo & video recorder

    · Video output (USB)

    · 32Gb Internal memory

    · Built-In WiFi module

    · Functional App

    · Power saving "Standby" Mode

    · Multiple colour, display & observation modes

    · Fast start-up

    · Image Enhancement Mode (DDE)

    · Ergonomic design

    · Centralised controls

    · Focusable lenses


    Technical Data Sheet
     TracerLRF 35TracerLRF50
    Detector
    TypeUncooled Vox
    Resolution384×288
    Frame rate50Hz
    Pitch17μm
    Spectral range8-14μm
    NETDLess than 35mk
    Optical Characteristics
    Objective lens35mm50mm
    Magnification2.7x3.9x
    FOV10.6°×8.0°7.4°×5.6°
    Close-up range5m
    Dioptre adjustment-5D-4D
    Functions
    ZoomSmooth digital zoom
    Palette5 optional(can be customized)
    Start up timeLess than 5 seconds
    Start up imageCan be customized
    Menu and informationGUI(Can be customized)
    Image enhancementDDE
    Contrast and brightnessAGC
    Online updateBoth code and GUI resources
    Display
    TypeOLED
    Resolution1024×768
    Power Supply
    BatteryBuilt-in lithium battery
    External power supply5V micro USB
    Battery life8h+
    Physical Characteristics
    Weight without battery540g590g
    Size155x50x92mm165x56x92mm
    Environmental Compatibility
    Water proofIP67
    Operating temperature-20℃-50℃
    Storage temperature-40℃-60℃
    Laser Rangefinder
    Safety class for laser equipment
    according to IEC 60825-1:2014
    1
    Measuring range5-1000m
    Measurement accuracy±1m
