    Field Search THH3 Thermal Imaging Scope 5 Hours Working Time WiFi Supported

    Ask Lasest Price
    Brand Name : Nightseer
    Model Number : THH3
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 10000 PCS PER YEAR
    Delivery Time : 7-30 Days
    Certification : ISO,CE,ROSH
    • Product Details
    • Company Profile

    Field Search THH3 Thermal Imaging Scope 5 Hours Working Time WiFi Supported

    Field Search THH3 Thermal Imaging Scope 5 Hours Working Time WiFi Supported

    Advantages :


    1. LENS

    Some monoculars in the market use Spherical lenses while THH3 uses F1.0 Aspherical lens. The aspherical lens gives the benefit of lighter weight and better transmissivity to make a better image. The cost difference between the two kinds of lens is approx. 150.00USD


    2. SENSOR

    Some monocular in the market are made from Chinese detector while THH3 uses latest Generation detector from ULIS, of which the image quality, stability, and reliability is much higher than Chinese detector, especially when used after 2 years in low temperature and high humidity environment. The cost difference between western and Chinese detector is about 300USD.


    3. DISPLAY

    Some monocular in the market uses 0.25” LCOS screen of which the resolution is 720*540 while THH3 uses 0.39” 1024*768 AMOLED, the clearance and image performance is at least 4 times better than LCOS. Especially when under the low-temperature environment of -40℃ , THH3 can still work without problem but other imagers with LCOS screen can not work even under -15℃. The cost difference between OLED and LCOS is approx. 250USD


    SPECIFICATION
    THERMAL IMAGING
    ModelTHH3(15)THH3(25)
    Sensor type

    Vanadium oxide uncooled detector
    Image size384 X 288
    Response band
    8~14um
    NETD
    Noise equivalent temperature diference
    < 40mk(@25*C,F#=1.0)
    F data
    1
    Lens focal length
    15mm25mm
    Field of view angle
    25°* 19°16°*12°
    IMAGE DISPLAY
    Monitor0.39 inches,AMOLED,1024*768
    Image modewhite hot, black hot, cold red,red hot
    SYSTEM FUNCTIONS
    Digital zoom
    Support(1X/2X/4X)
    CrosslineSupport
    WIFI hotspotSupport
    Ranging
    Support
    Picture in picture

    Support
    Video
    Support
    White light illumination
    Support
    StorageSupport
    OTHER
    Battery full power usage time≥5h(Can add charging treasure to increase time)
    Charging system
    charger
    Operating temperature
    —40~60°C
    Protection level
    IP67
    Anti-fall rating
    2m
    Installation method
    Handheld
    Size
    74*66* 189(mm)
    Weight<0.5kg



    SALES & SERVICE


    We try our best to make sure all customers can get proper training of our device and good after-sell service when any kind of failure occurs.

    We understand that as a manufacturer it is important to work tightly with our distributors to support customers from different regions.


    QUALITY CONTROL


    We understand that in some cases, lives may depend on the performance of our products, that is why every unit that leaves our facility must pass tough quality control standards testing.

    It is our mission to continue to design, build, test and ship the very best optoelectronics devices on the market.
